Vacuum Tube Rectifier 5U4G Vacuum Tube Replace 5Z3P GZ34 274B Tubes Precision Pairing Used for Audio Amplifier(5u4g 2pcs)
Vacuum Tube Rectifier 5U4G Vacuum Tube Replace 5Z3P GZ34 274B Tubes Precision Pairing Used for Audio Amplifier(5u4g 2pcs)
vacuum tube
The has good linearity low noise and good reliability
The tube is designed for service as power rectifiers in AC operated receivers which require high currents.
The service life longer and the failure rate greatly reduced.
The special with signal and has low noises output.
The has good linearity low noise and good reliability
The tube is designed for service as power rectifiers in AC operated receivers which require high currents.
The service life longer and the failure rate greatly reduced.
The special with signal and has low noises output.
Quantity
-
Detail
vacuum tube
Filament heating
Uf..................5V
If............ 3A
limit rating
Anode reverse voltage peak............1550V
Anode current peak ......675mA
Recommended work status
Anode supply voltage 2×500V
Impedance 75 per arm
Load impedance 2000
Filter capacitor 40F
Rectified current 230mA
==========
Channels : 1
Model Number : 5U4G Vacuum Tube
Maximum Power Per Channel : NO POWER
Origin : Mainland China
type : 5U4G Vacuum Tube 5U4G Tube 5U4G 5U4G TubeS -
